BLUETTI PV420 Solar Panel | 420W
Free Shipping
12 Months Hassle-Free Warranty
After Sales Customer Support
Price Match Guarantee
Specifications
- Power: 420W
- Lamination: ETFE (Ethylene tetrafluoroethylene)
- Cell Type: Monocrystalline Silicon
- Open Circuit Voltage (OCV): 44.3V
- Short Circuit Current (Isc): 12.2A
- Connector: Standard MC4 Connector
- Weight: 14kg (30.8lbs)
- Dimensions (Unfolded): 105.3*38.3in / 2675*975mm
- Dimensions (Folded): 38.3*25.9*1.7in / 975*660*45mm
- Temperature: 14°F-149°F/-10°C-65°C
- Best WorkingTemperature: 77°F (25°C)
- Cable Length: 118in (3m)
- Certifications: FCC, CE, ROHS
- Warranty: 12 Months
Download the USER MANUAL HERE.
More Power For Less
With a high-powered PV420 solar panel hooked up, you can juice up your battery with solar energy at a high speed, meeting your power demand while saving your bills in the long run.
Up-Level Your Solar Lifestyle
As a game-changer for collecting solar energy, BLUETTI PV420 is compact and foldable for easy transportation. No need to rely on the grid whether you go on outdoor adventures or stay at home.
Optimal Solar Intake
Given the 23.4% high conversion rate, PV420 is capable of capturing about 2kWh solar energy every day with 6 hours of prime sunshine (under ideal conditions), enough to run your electronics for hours.
Beef Up Productivity
Simply set up your solar panel and adjust the tilt based on the sunlight intensity or angle to generate the optimal solar power. Your power-hungry devices will never lose power again with a continuous solar supply.
Hassle-free Carrying
The foldable design saves much valuable space in the trunk or storage room. A convenient handle is designed to make it effortless to carry wherever there's the most sunlight.
FAQ
#1 Is PV420 It Waterproof?
BLUETTI PV420 has undergone enough reliability tests and offers an IP65 water resistance rating. However, to get an even longer lifespan in the right environment, we don’t suggest putting them in direct contact with rain for too long.
#2 Can I install it on the roof?
No.
#3 Can I use BLUETTI Solar Panel to charge the third-party power station?
Yes, as long as they
(1) have MC4 connectors;
(2) have compatible specifications consistent with the voltage output of BLUETTI solar panels..
#4 BLUETTI PV350 compatibility.
Most solar power stations on the market, and one PV350 solar panel is ideal for BLUETTI AC200P/AC200MAX/AC300+B300 solar generators.
#5 How do I choose compatible solar panels for my solar generator?
Always keep in mind that a solar panel is a long-term investment, hence there are many aspects other than the price that you should take into consideration.
1.PV input of your solar generator
2.Output of the solar panel
3.Voltage of the solar panel
4.Wattage of the solar panel
5.Current of the solar panel
6.Solar input connectors
#5 Can I mix different types of solar panels?
No. Mixing different solar panels is not encouraged in general. To get the maximum efficient solar panel system, we recommend you use solar panels of the same type and from the same vendor.
For example, two PV200 charging BLUETTI AC200P is acceptable, while one PV200 + one SP120 is not suggested.
#6 Does the panel have any USB ports you can directly plug into?
No. BLUETTI PV420 only has MC4 connectors.
#7 What are the factors that affect a solar panel's efficiency?
Multiple factors play roles in limiting a solar panel's ability to convert the sunlight it receives, like weather, sun intensity, shading, panel orientation, temperature, location, etc.
#8 How do I maximize the efficiency of the solar panel?
These steps will help you get the most out of your solar panels:
1. Set up your panels correctly: The orientation as well as the angle it tilts at should be right.
2. Avoid shadow areas: Any amount of shadow will affect solar panel production.
3. Keep your panels clean: Dirt or debris reduces the panel’s efficiency.
4. Don’t get panels too hot: Good air circulation or a cool atmosphere around panels will help.
