BLUETTI AC200MAX Power Station | 2200W 2048Wh
• 2,048Wh Capacity
• LiFePO4 Battery with 3,500+ Life Cycles to 80%
• 1,440Wh Larger Capacity*
• Expandable Up To 6,144Wh with 2×B230, or 8,192Wh with 2×B300
• 7 Ways to Recharge (AC/Solar/Car/Generator/Lead Battery/Dual AC/AC+Solar)
• 900W Max. Solar Input
• 1400W Max. Fast Dual Charging (Solar + AC Adapter)
• Smart Control & Monitor in BLUETTI App
Receive your items within 1–3 business days across New Zealand. For wholesale orders, please contact us to arrange customised shipping solutions.
Features
SMALL CHANGE, HUGE LEAP
It’s here: The first modular, expandable Bluetti power station. Packed with an astonishing 2048Wh ultra-durable LFP cells and a 2,200W full power pure sine wave inverter, the AC200MAX can be your mobile recharge center off-the-grid or on the way.
Less To Spend, More To Love
Struggling between power and flexibility? We got you covered! With two expansion ports, The AC200MAX welcomes up to two BLUETTI B230’s(2048Wh each) or B300(3072Wh each) battery modules, connecting of which can boost the total capacity to a staggering 8192Wh!
Get Charged In Anyway You Prefer
The AC200MAX allows up to 900W of solar input and 500W via the adapter, you can even charge it up via your wall outlet and solar panels simultaneously, boost a stunning 1400W total charging rate which can top up your power beast in less than two hours! Furthermore, every BLUETTI battery module has their own input port for AC adapters, you’ll get another 500W of input capability with every module added (Up to two for the AC200MAX).
Small Change, Huge Leap
The AC200Max can now take one module via its solar input port with a converter cable for extra capacity!
Incomparable Outlet Versatility
With AC200MAX’s 15 outlets, you get to run all your needs simultaneously without breaking a sweat.
Tech Specs
| BATTERY INFO | Capacity: | 2048Wh (51.2V,40Ah) |
| Type: | LiFePO4 (Lithium Iron Phosphate) | |
| Life Cycles: | 3,500+ Cycles to 80% Original Capacity | |
| Shelf-life: | Recharge to 80% Every 3-6 Months | |
| Management System: | MPPT Charge Controller, BMS, etc. |
| OUTPUT | AC Output: | 4 x 220V-240V,2200W In Total |
| Surge Power: | 2,700W | |
| USB-C Port: | 1 x 100W Max. | |
| USB-A Port: | 2 x 5V/3A USB-A 2 x 18W USB-A | |
| Wireless Charging Pad: | 2 x 15W Max. (For Each) |
| INPUT | AC Input: | 500W Max |
| Solar Input: | 900W Max.OCV 10-145VDC, 15A | |
| Car Input: | 12/24V from Cigarette Lighter Port | |
| Max Input: | 1,400W, with AC+Solar Input |
| RECHARGE TIMES | AC Adapter (500W): | ≈5.5~6 Hours |
| Solar (900W): | ≈3~3.5 Hours (With prime sunshine, ideal orientation and low temperature) | |
| 12V/24V Car Outlet (100W/200W): | ≈10 or 20 Hours | |
| AC Adapter + Solar (1400W): | ≈2.0~2.5 Hours (With prime sunshine, ideal orientation and low temperature) | |
| Dual AC Adapters (1000W): | ≈3~3.5 Hours (Extra adapter is required) |
| GENERAL | Pass-through Charging: | Yes |
| Weight:: | 28.1kg 61.9lbs | |
| Dimensions (LxWxD): | 16.5 x 11 x 15.2 in ( 42 x 28 x 38.65cm) | |
| Operating Temperature: | -4-104℉ (-20-40℃) | |
| Storage Temperature: | 14-113℉ (-10-45℃) | |
| Certification: | UL2743, UKCA, TELEC, RCM, FCC ID, CE, PSE, NTC | |
| Warranty: | 48 Months |
| DOWNLOAD MANUAL HERE |
SMALL CHANGE, HUGE LEAP
It’s here: The first modular, expandable Bluetti power station. Packed with an astonishing 2048Wh ultra-durable LFP cells and a 2,200W full power pure sine wave inverter, the AC200MAX can be your mobile recharge center off-the-grid or on the way.
Less To Spend, More To Love
Struggling between power and flexibility? We got you covered! With two expansion ports, The AC200MAX welcomes up to two BLUETTI B230’s(2048Wh each) or B300(3072Wh each) battery modules, connecting of which can boost the total capacity to a staggering 8192Wh!
Get Charged In Anyway You Prefer
The AC200MAX allows up to 900W of solar input and 500W via the adapter, you can even charge it up via your wall outlet and solar panels simultaneously, boost a stunning 1400W total charging rate which can top up your power beast in less than two hours! Furthermore, every BLUETTI battery module has their own input port for AC adapters, you’ll get another 500W of input capability with every module added (Up to two for the AC200MAX).
Small Change, Huge Leap
The AC200Max can now take one module via its solar input port with a converter cable for extra capacity!
Incomparable Outlet Versatility
With AC200MAX’s 15 outlets, you get to run all your needs simultaneously without breaking a sweat.
| BATTERY INFO | Capacity: | 2048Wh (51.2V,40Ah) |
| Type: | LiFePO4 (Lithium Iron Phosphate) | |
| Life Cycles: | 3,500+ Cycles to 80% Original Capacity | |
| Shelf-life: | Recharge to 80% Every 3-6 Months | |
| Management System: | MPPT Charge Controller, BMS, etc. |
| OUTPUT | AC Output: | 4 x 220V-240V,2200W In Total |
| Surge Power: | 2,700W | |
| USB-C Port: | 1 x 100W Max. | |
| USB-A Port: | 2 x 5V/3A USB-A 2 x 18W USB-A | |
| Wireless Charging Pad: | 2 x 15W Max. (For Each) |
| INPUT | AC Input: | 500W Max |
| Solar Input: | 900W Max.OCV 10-145VDC, 15A | |
| Car Input: | 12/24V from Cigarette Lighter Port | |
| Max Input: | 1,400W, with AC+Solar Input |
| RECHARGE TIMES | AC Adapter (500W): | ≈5.5~6 Hours |
| Solar (900W): | ≈3~3.5 Hours (With prime sunshine, ideal orientation and low temperature) | |
| 12V/24V Car Outlet (100W/200W): | ≈10 or 20 Hours | |
| AC Adapter + Solar (1400W): | ≈2.0~2.5 Hours (With prime sunshine, ideal orientation and low temperature) | |
| Dual AC Adapters (1000W): | ≈3~3.5 Hours (Extra adapter is required) |
| GENERAL | Pass-through Charging: | Yes |
| Weight:: | 28.1kg 61.9lbs | |
| Dimensions (LxWxD): | 16.5 x 11 x 15.2 in ( 42 x 28 x 38.65cm) | |
| Operating Temperature: | -4-104℉ (-20-40℃) | |
| Storage Temperature: | 14-113℉ (-10-45℃) | |
| Certification: | UL2743, UKCA, TELEC, RCM, FCC ID, CE, PSE, NTC | |
| Warranty: | 48 Months |
| DOWNLOAD MANUAL HERE |
FAQ
How many BLUETTI B300 or B230 expansion batteries can connect with the AC200MAX?
Two B300 for 8,192Wh capacity.
Two B230 for 6,144Wh capacity.
Can I connect third-party expansion batteries to AC200MAX?
No. AC200MAX ONLY accepts BLUETTI B230 or B300 expansion batteries.
Does AC200MAX support App control?
Yes. Once connected via Bluetooth, the BLUETTI App will enable you to control the AC200MAX remotely, like switching the working mode and upgrading the firmware.
Can I use AC200MAX as a UPS?
No.
QuestionWhat kind of solar panels should I choose for AC200MAX?
PV input requirements for AC200MAX:
1. Open Circuit Voltage: 10-145V
2. Input Power: 900W Max.
3. Include MC4 connectors.
Highly Recommended:
6x BLUETTI PV120: ≈3.5hrs.
4x BLUETTI PV200: ≈3hrs.
2x BLUETTI PV350: ≈3.5hrs.
* For reference ONLY."
Can I connect two units of AC200MAX together for more power?
No.
Is the AC200MAX power station waterproof?
Can it charge and discharge at the same time?
Yes
Can I use or charge AC200MAX in sub-zero temperatures?
Temperature ranges for AC200MAX are:
Charge: 0-40℃ (32-104℉);
Discharge: -20-40℃ (-4-104℉);
Storage:-10-45℃ (14-113℉ ).
Technically, it can power electrical devices under such situations, but please avoid charging it.
How do I know whether my appliance can work well with the AC200MAX?
Calculate the total wattage of your devices. AC200MAX should work if the load doesn't exceed its rated 2,200W.
How long can it run my device?
Running time = Battery capacity × DoD × η ÷ Device rated power
DoD refers to Depth of Discharge and η is local inverter efficiency.
For AC200MAX, both DoD and η are 90%. If you run a 1,000W microwave oven with it, the running time will be:
2,048Wh × 90% × 90% ÷ 1,000W ≈ 1.65hrs
Note:
1) The formula is NOT suitable for inductive loads with compressors, like refrigerator, air conditioner, etc.
2) The above data is for reference ONLY.
What is the maximum input charging power of the BLUETTI AC200MAX?
1,400W Max. Via 500W wall socket and 900W solar panels simultaneously.
Can it be laid on its side to save space?
No. Long-term placement will make the internal structure loose, it is recommended to place the machine upright.
Can I hot-swap expansion batteries to AC200MAX?
Yes. You can easily swap battery packs for continuous power use, and the system can hold two batteries at once.
Is it possible to replace the built-in battery?
No. If the battery pack is faulty or even dead, please contact BLUETTI Customer Service.
What is the difference between the AC200MAX and AC200P?
The main differences are:
1. Output power and capacity: 2,200W AC power and 2,048Wh capacity for AC200MAX, while 2,000W and 2,000Wh for AC200P.
2. Max. Input: 1,400W for AC200MAX, while 1,200W for AC200P.
3. App Control: AC200MAX supports BLUETTI App control.
I'd like more tutorial videos on the AC200MAX.
Sure, please follow BLUETTI Support on YouTube
Why does a warning come up when using a diesel heating pump with the cigarette lighter port?
The pump may require more initial power to start. Use a compatible adapter to start and run the pump with our AC outlets
